Inverter (UPS) ANENJI 4000W 24V Wi-Fi

The ANENJI ANJ-4000W-24V-WIFI inverter is a hybrid device that combines the functions of an inverter, solar charger and battery charger. It is designed for off-grid and grid-tied power supply systems such as homes, cottages, campers and boats.

📄 User Manual

For detailed information on setting up and operating the inverter, you can download the user manual from the following link: 4000W pdf

You may also need a battery? Click here:

ANENJI, 100Ah capacity, 24V

⚙️ Main features

Model: ANJ-4000W-24V-WIFI

Nominal power: 4000W

Peak power: 7000W

Output voltage: 220/230VAC

Output waveform: Pure sine wave

Power factor: 1.0

Battery input voltage: 24V

Maximum battery charging current: 100A

MPPT voltage range: 60-500VDC

Maximum input power from solar panels: 4000W

Efficiency: Up to 93%

Battery transfer time: 10ms

Supported battery types: Li-ion, LiFePO₄, lead-acid

Communication interfaces: RS232, RS485, Wi-Fi

Display: LCD display for setup and monitoring

Dimensions: 358 × 295 × 100 mm

Weight: 7 kg

🛡️ Protection and functions

Protection against: overload, overheating, short circuit, reverse polarity

UPS function: provides uninterruptible power supply when the network is disconnected

Cooling: Active (fans)

Operating temperature: from -10 to +55 °C

📦 Package and additional options

Package: Inverter, user manual

Additional: Possibility of connecting a Wi-Fi module for remote monitoring
