Excavator loader 3 in 1

Specifications JCB 3CX, weight Various attachments can be installed on the base model and its modification. These are buckets (standard, jaw, conical, deep, for digging ditches), and forks. Special attention should be paid to the universal jaw bucket "6 in 1", it digs, shifts, loads, captures, levels the ground and fills ditches. The maximum digging depth of the JCB 3CX SAE (ground to bottom wall of the bucket) with a standard stick is 4.24 m. The 3CX Super has a maximum digging depth of 4.37 m. 5.46 and 5.5 m respectively. Ground clearance (0.37 and 0.33 m) allows special equipment to work on uneven surfaces. JCB 3CX JCB 3CX Super Operating weight with 6-in-1 jaw bucket 8,070 kg 8,425 kg Maximum lift capacity 2,882 kg 4,638 kg Dump height 2.72 m 2.64 m Digging depth (cut thickness) 0.10 m 0.23 m Dumping angle 43° 44° Max dig depth 4.24/5.46 m 4.37/5.58 m Max dump height 3.33/4.22 m 3.4/4.22 m Swing angle bucket 201° 201° Engine The 3CX series, which is intended for the Russian market, is equipped with 4.4-liter JCB Dieselmax 4-cylinder power units (Tier II or Tier III). The turbocharged engine that powers the 3CX Super is more powerful (92 vs. 85 hp on the base 3CX) and has more torque (400 vs. 320 Nm). Depending on the operating mode, fuel consumption on the 3CX varies from 6 to 10 liters, on the Super - from 9 to 15 liters per hour. This efficiency is achieved due to the increased torque in the lower rev range. JCB 3CX JCB 3CX Super Engine power 85 hp 92 HP Maximum torque (at 1200 rpm) 320 Nm 400 Nm Maximum driving speed in 4th gear 40 km/h 37 km/h
