We offer special gypsum bandage production line:
1) Type: single-layer, horizontally rotating.
2) Max. working width: 1050mm; guide roller width: 1200mm.
3) Min. working width: 950mm.
4) Design speed: 10-40m/min.
5) Line external dimension (L*W*H): 40410×3030×2000mm
6) Total weight: 30t.
7) Transmission: AC multi-cycle motor and frequency converter synchronously adjust the speed and transmission.
8) Control method: independent needle plate.
9) Thermal dryer: 220℃（Max）
10) Heat source: hot wind.
11) Used voltage: 380V(±5%)50HZ 3PH
12) Control system power supply: 220V and 24V
13) Installed power: 120KW
14) Heat consumption: the maximum consumption of each drying cabinet: 75000KCAL/HR
15) Main drive: using 15KW electric motor, and the control method of frequency converter.
