Dump truck Kamaz-65222

TOO "AvtoTrade-K", the official dealer of JSC "KAMAZ-Engineering" in the Republic of Kazakhstan, invites you to consider the possibility of purchasing the following vehicles on the KAMAZ chassis:
WEIGHT PARAMETERS AND LOADS
Carrying capacity of the vehicle, kg 19580
Gross weight of the vehicle, kg 34000
Load on the rear bogie, kg 26000
Load on the front axle, kg . 8000
Curb weight, kg 14425
Load on the rear bogie, kg 8000
Load on the front axle, kg 6425
ENGINE
Engine model 740.735-400 (Euro-5)
Cylinder diameter and piston stroke, mm 120/130
Max. useful torque, Nm (kgcm) 1766 (180)
at crankshaft speed, rpm 1300
Maximum useful power, kW (hp) 294 (400)
at crankshaft speed, rpm 1900
Displacement, l 11.76
Arrangement and number of cylinders V-shaped, 8
Fuel supply system Common Rail
Compression ratio 18.0
Engine type diesel with turbocharging, with intermediate cooling of charge air
GEARBOX
Model ZF 16S1820TO
Type mechanical, sixteen-speed
Control mechanical, remote
MAIN GEAR
Gear ratio 6.88
Type double, with central bevel gear and planetary wheel gears
CABIN
Version with a sleeping berth
Suspension pneumatic
Type of cabin located above the engine, with a high roof
WHEELS AND TIRES
Rim size 11.25-20
Type of wheels disc
Type of tires pneumatic, tube
Tires 16.00 R20
TRANSFER BOX
Type mechanical, two-stage with a lockable center differential
Control pneumatic
DUMP PLATFORM
Direction of unloading back
Platform volume, cubic meters 16
Platform elevation angle, degrees 50
POWER SUPPLY SYSTEM
Fuel tank capacity, l 350
CLUTCH
Type diaphragm, single-disc, mod. ZF&SACHS MFZ 430
BRAKES
Pneumatic drive
Dimensions drum diameter, mm 420
Brake lining width, mm 180
CAR CHARACTERISTICS OF GROSS WEIGHT
Outer overall turning radius, m 12
Maximum speed, not less than, km/h 90
Angle of climb, not less than, % (deg) 25 (14 deg.)
ELECTRICAL EQUIPMENT
Batteries, V/A h 2x12/190
Generator, V/W 28/3000
Voltage, V 24
