Asphalt roller DYNAPAC CC1200 VI

DYNAPAC CC1200 VI 6th Generation Small Asphalt Compactor weighing 2.6t, with a drum width of 1200mm (46") is designed for compaction in city streets where size and noise matter most. The new roller has a working weight range of up to 3100 kg. This model features an improved design and a new engine that is quieter than ever. We are the official distributor of DYNAPAC in the territory of the Republic of Kazakhstan, we offer favorable leasing conditions. We sell road construction equipment with subsequent service and technical support throughout the entire period of its operation. We always have consumables for maintenance of road rollers in our warehouse. For whatever purpose you would need a road roller, we are ready to select and deliver to your address a suitable roller for your soil or asphalt compaction tasks. The cost of goods can be changed depending on the exchange rate. Weight Maximum operating weight, kg 3400 Weight of the front module/rear module, kg 1230/1370 Chassis Speed range, km/h 0-10 Theoretically gradeable,% — 43 Vertical oscillation, — 10 Consolidation Centrifugal force, kN — 27 Nominal amplitude , mm - 0.5 Vibration frequency, Hz 57 Engine Manufacturer / Type - Kubota D1703-M (T4i) Rated power, SAE J1995 - 26 kW (35 hp) at 2,800 rpm A. Wheelbase 1700 mm B. Width 1340 mm B3. Width, with side offset 50 mm C. Curb clearance 554 mm D. Drum diameter 702 mm H1. Height with ROPS/cab 2542 mm H2. Height without ROPS/cab 1744mm K. Ground clearance 180mm L. Length 2400mm O1. Frame offset, right 70 mm O2. Frame offset, left 70 mm R1. External turning radius 3770 mm R2. Internal turning radius 2570 mm S. Drum shell thickness 13 mm W. Drum width 1200 mm?. Steering angle 30
